BATTERY POWERED STOCK TANK HEATERS

Cold Weather Colicing Prevention.

Keep remote stock tanks from freezing solid with our #SJH series water heaters! People have found that using our battery powered heaters is the BEST deicing method ever devised! Keep water available to your live stock 24 hours a day. While the 12 volt battery needs to be changed out ONCE a day it sure beats chopping ice 3 or 4 times a day!
Compared to endless ice chopping simply swapping out batteries once a day is relatively easy!

(You can also use much bigger batteries and go as long as 4 days. For more info read all info below)


Our 12 volt heater is fast and easy to
wire up with any 12 volt car battery!

THREAD-IN BATTERY POWERED STOCK TANK HEATERS

#SJH126F heater with freeze sensor for 12 volt systems- 6" model


Ratings; (Ni-Chrome coils / High Wattage)
12 volt @ 600 watts - Thread-In Model (1" NPT bottom tap)
40 F. "ON" to 60 F. "OFF"
Special build for 50 amps / 600 Watts

ONLY $149.95 + $24.90 S&H each
ONE 12 volt heater w/freeze sensor












NOTE: do not put any kind cold proofing insulation between the tank and freeze sensor.
it must remain exposed to cold air and not only the warmer water in the base of the tank.

THREAD-IN BATTERY POWERED STOCK TANK HEATERS

Cold Weather Colicing Prevention.

Threaded models fit right into the bottom
of all 1" water tank drain plugs. (1" NPT - bottom tapped)

Built to last a lifetime.
Low voltage means NO shock hazard.
STOP expensive and deadly Colic !
WARNING: do not put any kind cold proofing insulation between the tank and freeze sensor.
It must remain exposed to cold air and not only the warmer water in the base of the tank.


BUY HEATER ONLY
Threaded models fit right into the bottom of all 1" water tank drain plugs. (1" NPT - bottom tapped)
BUY ONE HEATER NOW



Our 12 volt heater is fast and easy to
wire up with any 12 volt car battery!

THREAD-IN BATTERY POWERED STOCK TANK HEATERS

#SJH126F heater with freeze sensor for 12 volt systems- 6" model


Ratings; (Ni-Chrome coils / High Wattage)
12 volt @ 600 watts - Thread-In Model (1" NPT bottom tap)
40 F. "ON" to 60 F. "OFF"
Special build for 50 amps / 600 Watts

ONLY $149.95 + $24.90 S&H each
ONE 12 volt heater w/freeze sensor













WARNING: do not put any kind cold proofing insulation between the tank and freeze sensor.
It must remain exposed to cold air and not only the warmer water in the base of the tank.

BUY COMPLETE KIT
If you do not want to drill holes in tanks get a Plunge-Probe Full Water Heater Kit -
Includes drop in heater probe and Freeze Sensor all in one unit / Just Plug-And-Play

BUY 600 Watt Drop-in /Plunge-Probe Kit - $239.95 Plus S&H
Note: If you purchase the plunge-probe kit it will come directly wired into the Freeze sensor module.

WARNING: do not put any kind cold proofing insulation between the tank and freeze sensor.
It must remain exposed to cold air and not only the warmer water in the base of the tank.




If you do not want to drill holes in tanks? Get our Easy-To-Use / Drop-In / PLUNGE-PROBE
34" long by 3/4" PVC plunge-probe. Can be extended with ordinary PVC pipe fittings.
Comes with heavy duty 12 AWG water proof wire.
Just clip on to a 12 Volt Marine battery or buy with our Freeze Sensor Module for cold
weather automation and automatic ON-OFF
Drop in Plunge-probe is sealed at base and top with silicon rubber for years for long life.

EASY PLUG & PLAY - Just clip the 2 power terminals to any 12 volt
car or boat battery and probe will start heating your water tank fast.
(Make sure the probe is covered in water at all times so it does not over-heat)
BUY 600 Watt Drop-in / Plunge-Probe for $99.95 Plus S&H

Simply clip on to a 12 Volt Marine battery or buy with our Freeze Sensor Module for cold
weather automation and automatic ON-OFF (See Below under "Freeze Sensor Module")
Drop in Plunge-probe is sealed at base and top with silicon rubber for years for long life.

Note: If your purchase the probe only it will come with battery clips for
direct connection to battery. Heats water instantly and for about 12 hours
if hooked to a large deep cycle battery.



Freeze Sensor Module ADD-ON part for Plunge-Probe

BUY A FREEZE SENSOR FOR YOUR PLUNGE-PROBE! Turns your probe into an automatic unit that only turns
on in freezing weather. Saves battery life and is a great sentry-device that can be there ready to heat water while your away.

Plunge-Probe Freeze Sensor Module kit to Automate Plunge Probe $129.95 Plus S&H

Note: If your purchase the probe together with Freeze sensor it will come with
different electrical fittings that adapter right into this unit.






Extending battery time - Batteries can also be banked together in PARALLEL (not series) to extend the time in between visits to remote stock tanks. You can also extend the running time by up to 4 times by using 6 volt "GOLF CART" batteries and running the heater on only 6 volts. On a 6 volt battery they will last 4 times longer in between charges BUT they will not run as HOT either which could work out nice for smaller or really remote tanks!
In any case there are lots of wiring configurations you can experiment with in-order to get the right heating curve and longevity out of your batteries.
You can also use a wind turbine or solar panel to help charge batteries in the field too! Only you can determine what will work in YOUR situation so pay close attention to the water for the first few days your heater is on line!

Why does battery power work so well? Even during the day when temperatures rise above freezing the water is being slowly heated by the water heater.

This large body of warm water acts as a gigantic heat sink (Thermal Mass) and the water will hold that heat all night long, especially if you insulate the tank too!


EXAMPLE: If you have ever unplugged a portable spa you will have noticed that even days later the water is still very warm even in freezing weather. This is why slow heating of water both day and night with a low wattage battery powered heater works out so well.

IMPORTANT HINTS:
Insulation of the water tank by surrounding it with straw bails and or applying a spray-able foam type insultation is very important to stop heat dissipation!
Also the battery powering your heater should be placed in a closed box with at least 4" of foam insulation to keep its power levels higher in cold weather.
Note: Large tanks should be siting on solid Styrofoam billets that are at least 6" thick. The ground is very COLD!!


"Swopping out a battery daily sure beats chopping ice everyday"





Water Heating Elements Only


#SJH12600 - for 12 volt heater ONLY 6" model
#SJH12600 model features standard electric terminal screws and is zinc plated with rubber gasket.
Ratings; (Ni-Chrome-Ruthenium coils / Low Wattage)
(SPECIAL HIGH EFFICIENCY Ruthenium doped MODEL)
6 volt @ 75 watts / 12 volt @ 600 watts (15 volts - Max Battery VDC =750 watts) -
Thread-In Model (1" NPT bottom tap) Probe MUST be under water at all times!


ONLY $39.95 + $22.90 S&H each

#SJH24600 - for 24 volt heater ONLY 6" model
#SJH24600 model features standard electric terminal screws
and is zinc plated with rubber gasket.
Ratings; (Ni-Chrome coils / High Wattage)
24 volt @ 600 watts - Thread-In Model (1" NPT bottom tap)

#SJH24600 - ONLY $59.95 + $19.90 S&H each
ONE heater
(30 volts - Max Battery VDC =750 watts) -
Thread-In Model (1" NPT bottom tap) Probe MUST be under water at all times!
IDEAS: Power Saver -
If you connect a 24 Volt / 600 Watt rated heater to a 12 volt battery it will THEN only draw 150 Watts, great for stopping small water tanks from freezing for LONG periods of time.





#SJH12300 - SPECIAL HIGH EFFICIENCY for 12 volt systems - 6" model
#SJH12300 model features standard electric terminal screws and is zinc plated with rubber gasket.
Ratings; (Ni-Chrome-Ruthenium coils / Low Wattage)
(SPECIAL HIGH EFFICIENCY Ruthenium doped MODEL)
6 volt @ 75 watts / 12 volt @ 300 watts (15 volts - Max Battery V/375 watts) -
Thread-In Model (1" NPT bottom tap)


ONLY $59.95 + $19.90 S&H each (SPECIAL HIGH EFFICIENCY Ruthenium doped MODEL)
ONE heater




#SJH48600 - for 48 volt systems- 8" model
Ratings; (Ni-Chrome-Ruthenium coils / Low Wattage)
48 volt @ 600 watts / 60 volt @ 680 watts
Thread-In Model (1" NPT bottom tap)

ONLY $39.95 + $19.90 S&H each
ONE heater





For use with in any 50 amp or higher common LOW VOLTAGE 12 volt automotive battery charger and then simply hook the 12 Volt leads to your #SJH600 heater with 10 gauge wires.

Remember NEVER to heat your animals water with a direct high voltage 110 Volt plug-in heaters as this practice regularly kills an estimated 17,000 animals annually once the high voltage heater gets a crack in the electrical insulation material!

NOTE: Only use Low Voltage heaters like ours that run on battery power or operate from a low voltage power transformer like a battery charger!!

Low Voltage 12, 24 + 48 VDC water heaters make accidental electrocution improbable! Heat your water safely this winter!


Your Critter NOSE (knows) the
dangers of ALL 110 volt heaters.




Remember NEVER to heat your animals water with a high voltage 110 Volt heaters as this practice regularly kills
an estimated 17,000 animals annually once the high voltage heater gets a crack in the electrical insulation material!

NOTE: Only use Low Voltage heaters like ours that run on battery power
or operate from a low voltage power transformer like a battery charger!!

LOW VOLTAGE 12, 24 and 48 Volt water heaters makes
accidental electrocution impossible! Heat your water safely!

Do not buy the 110 VAC killer heaters!! Sooner or later they always fail!






For HOT WATER direct from Wind Power CLICK HERE

No batteries needed!!




MORE HINTS:
Place the heater nearest to the side used most for drinking as warmwater rises just above the heater and this spot will be a MOST ice free.



Type #800 Incoloy Steel Jacketed Heater element with stainless hardware is manufactured to stringent UL® #1030 standards.

Overheat and Freeze thermostats available.

Official 90 day warranty (But if connections are protected they should last 15 to 30 years) Outdoor connections should be covered with grease to prevent corrosion)



Questions And Answers

Q. - Will it work on my rubber maid tank and what do you think of solar? Also how do I get maximum battery life in winter the months.
A - It works on most of the rubber maid tanks but you will have to check if it is a 1" pipe thread. Also we use a BOTTOM TAP NPT thread style so sometimes
you may have to re-thread the hole to the largest possible 1" taper but that is easy. I would highly recommend that you go to the smallest tank size possible in the winter months so the heater can do its job. Since the battery needs to be swapped out and the dead one recharged daily most people with 3 horses could get away with just a 20 to 30 gallon tank if re-filled daily. This does not mean you have to remove your big water tank but just offer the live stock an alternative drinking spot that is smaller and still liquid. The problem with solar is that the snow covers the panel so it also needs daily sweeping, The panels also cost about $1800.00 each for the Wattage needed to run the 600 Watt heater and the theft rate on an $1800.00 solar panel sitting in the middle of an open field is about 100% in the first year!

Q. -How does this all work? Please tell me what I need to do.
A. - Most of our customers connect a freshly charged deep cycle battery on their tank heater once every day at feeding time and then they JUST swap them out for a newly charged battery at that time. This means you will need two deep cycle batteries. One is operating the heater while the other one being recharged. No more chopping sheets of ice, battery swapping is all you need to do here. EASY! The water above the heater is always open. Also put straw bails around your tank and set the tank on an 8" bed of straw to keep it off of the cold ground. You can also build a dirt ramp around it for short animals if necessary.

Q. -Why is my battery only lasting 6 hours?
A. - First of all 6 hours of making warm water is very good because it may actually take the water 18 hours or more to cool back down to freezing so you have figure that into the whole timing equation. Having a tank with insulated walls that also is not siting on the ice cold ground will also help extend your warm water time dramatically.
Second, make very sure that you charge your battery up to a full 13.8 volts . This will give you TWICE the power of an ordinary 12 volt charge. This can be done by using a charger that has a "Boost" mode on it and a timer. Set it for 60 minutes on full BOOST mode. Using a charger that has a START/BOOST mode super charges your battery effectively doubling its energy output! Double check the charge with a volt meter and make sure its 13.7 volts or higher. If not, give it 60 more minutes of charging on the start/boost setting.You can also try buy a bigger DEEP cycle battery or even add many batteries in parallel to increase heating time. Insulate your batteries too. A cold battery is a dead battery! The BEST deep cycle battery is a TROJAN model # DC-500ML. This is the battery you should get! ( Rare facts: A 12 volt battery can be charged up as high as 14.7 volts) "Swopping out a battery daily sure beats chopping ice everyday"

Q. - CAN I CONNECT ONE OF THESE HEATERS DIRECTLY TO MY WIND TURBINE?
A - Yes but you must only use a model #SJH24125 heater in combination with the model #HT500/24 VOLT wind turbine! Buy Both as ONLY this combo works! This is the only combo proven not to 'stall-out' the wind turbine from spinning or burn-out the heater in a wind storm.

Q. My heater will not screw into the 1" NPT hole on my threaded tank.
A. We use a 1" BOTTOM TAP STYLE thread as it says in all of our ads. FIX - You need to buy or rent a 1" pipe tape and open up your thread ALL the way to the
maximum possible pipe taper so it will fit in the NOW 1" bottom taped threaded hole. Just run the pipe tap through the hole until the threads are fully cut up open to full size (bottom taped) Remember pipe thread is tapered. BOTTOM TAP means ALL THE WAY OPEN to the maximum taper. There is also a TAP called a bottom tap that does this right away. In either case you need to open up your threads wider, then it will fit into your 1" bottom taped hole.

Q. - I have your highest power 600 watt model and a big powerful battery at the full 13.8 volt charge but the water still freezes up by morning. What can I do?
A - You must be in an extremely cold area. The best thing you can do is get a smaller stock tank to concentrate the heaters energy into a smaller body of water. Also try to bring hot water with you when you fill your stock tank. Many ranchers fill their truck-tank directly from their home hot water heater. This water is burning hot at first but by the time you get out to the stock yard the water will be nice and warm and will melt all of the ice in the tank on contact ! (No Chopping). Now connect your freshly charged battery to your stock tank heater and you should be able to make it for a full 24 hours, until your next visit.


CHOPPING ICE IS NOT EFFECTIVE IN THE LONG

RUN AS THE COLD USUALLY WINS OUT IN THE END.

"Swopping out a battery daily sure beats chopping ice everyday"



How to buy a heater now

How to buy a thermostat to stop over heating or freezing

Heat water with wind power





 LEARN HOW TO MAKE A HOLE IN YOUR BUCKET OR BARREL







If you do not have a 1" NPT threaded hole at the bottom of your tank just buy a Bulkhead Fitting
BUY BULKHEAD TANK FITTINGS HERE
